F205 TRMS AC/DC clamp-on multimeter - Chauvin Arnoux

F205 compact and robust multimeter, includes all the essential features for your electrical measurements

F205 clamp-on multimeter with automatic AC/DC detection.
Power measurement and True InRush function for accurate measurement of electrical installations.
Phase rotation (two-wire method).
CAT IV 600 V.

See more information...

Customer warranty : 3 years

X

F205 TRMS AC/DC clamp-on multimeter - Chauvin Arnoux

£485.00

excl. VAT

£582.00 incl. VAT

unit

Item code:   AB12672

Add to Basket

Description

F205 compact and robust multimeter, includes all the essential features for your electrical measurements

F205 clamp-on multimeter with automatic AC/DC detection.
Power measurement and True InRush function for accurate measurement of electrical installations.
Phase rotation (two-wire method).
CAT IV 600 V.

F205 clamp-on multimeter supplied with 2x banana-banana test leads (red/black), 2x test probes (red/black), 1x black crocodile clip, 1x 9-V battery, 1x carry case, multilingual manual on mini-CD, multilingual quick-start guide.

Customer warranty : 3 years

Environmental and/or social benefits

This packaging is 100% recyclable, which means that at the end of its life, all of its components can be recycled separately via specific recycling facilities.

Specifications

Product Information

Product Name	F205 TRMS AC/DC clamp-on multimeter, AC/DC Max. current: 900 A, AC/DC Max. voltage: 1000 V
Brand	Chauvin Arnoux
Packaging	unit

Technical Specification

AC/DC Min. voltage (V)	0.15 V
AC/DC Max. current (A)	900 A
AC/DC Max. voltage (V)	1000 V
Min. AC current (A)	0.25 A
Max. AC current (A)	600 A
Min. DC current (A)	0.25 A
Max. DC current (A)	900 A
Min. resistance (Ohm)	0.1 Ohm
Resistance Max. (kOhm)	60 kOhm
Min. frequency (Hz)	5 Hz
Max. frequency (kHz)	20 kHz
EN Norm	EN 61010, Cat. IV 600 V, EN 61326-1, EN 61010, Cat. III 1000 V, EN 61010-1 (IEC 66-5)
Fully recyclable packaging	Yes - 100%
AC Min. voltage (V)	0.15 V
Lengths (mm)	222 mm
Display	6000-dot backlit LCD
Width (mm)	78 mm
AC Max. voltage (V)	1000 V
DC Max. voltage (V)	1000 V
DC Min. voltage (V)	0.15 V
Customer warranty	3 years
Cable Max. Ø (mm)	34 mm
Thickness (mm)	42 mm
